| № | Код | Название | Кол-во |
|---|---|---|---|
|
|
GEARCASE ASM,PRD. Incl. 1-40, 42-45, 47-55
|
1
|
|
|
1
|
CASE, LH
|
1
|
|
|
10
|
O-RING
|
4
|
|
|
11
|
WASHER
|
2
|
|
|
12
|
RING,RETAINING
|
2
|
|
|
13
|
BELLCRANK
|
2
|
|
|
14
|
WASHER
|
4
|
|
|
16
|
NUT-LOCK HEX FLANGE NYLON 5/16
|
2
|
|
|
17
|
SHAFT,HI/REV,SHIFT
|
1
|
|
|
18
|
BEARING
|
1
|
|
|
19
|
SHAFT, INPUT
|
1
|
|
|
2
|
SCREW
|
10
|
|
|
20
|
BEARING
|
3
|
|
|
21
|
SCREW-TAPPING,W/LOCK WASHER
|
4
|
|
|
22
|
PIN
|
2
|
|
|
23
|
BRACKET
|
1
|
|
|
24
|
SPRING
|
1
|
|
|
25
|
WASHER
|
2
|
|
|
27
|
BEARING,NEEDLE
|
1
|
|
|
28
|
WASHER
|
2
|
|
|
29
|
DOG,LOW,ENGAGEMENT
|
1
|
|
|
3
|
SEAL-TRIPLE LIP
|
3
|
|
|
31
|
WASHER
|
2
|
|
|
32
|
CHAIN,SILENT,34P
|
1
|
|
|
33
|
RING,RETAINING
|
1
|
|
|
34
|
SPROCKET UPDATE
|
1
|
|
|
35
|
BEARING,NEEDLE
|
1
|
|
|
36
|
VENT
|
1
|
|
|
37
|
DIPSTICK
|
1
|
|
|
38
|
O-RING
|
2
|
|
|
39
|
DISC ASM,BRAKE
|
1
|
|
|
4
|
BUSHING,PIVOT
|
2
|
|
|
40
|
RING,RETAINING
|
1
|
|
|
41
|
SPROCKET,11T
|
1
|
|
|
43
|
WASHER,SPRING LOCK10
|
1
|
|
|
44
|
BOLT 10
|
1
|
|
|
45
|
RING,SNAP10
|
1
|
|
|
46
|
SPKT,13T,SPLINED *
|
1
|
|
|
47
|
PLUG
|
1
|
|
|
48
|
WASHER
|
1
|
|
|
49
|
CASE, RH
|
1
|
|
|
5
|
STUD
|
3
|
|
|
50
|
DEFLECTOR,OIL
|
1
|
|
|
51
|
SPROCKET UPDATE
|
1
|
|
|
52
|
BEARING,NEEDLE
|
1
|
|
|
53
|
SPROCKET UPDATE
|
1
|
|
|
54
|
BEARING
|
2
|
|
|
6
|
PIPE, KNOCK
|
2
|
|
|
7
|
SHIFTRAIL,LOW
|
1
|
|
|
8
|
SHIFTRAIL,HIGH/REV. *
|
1
|
|
|
9
|
SHAFT,LOW SHIFT
|
1
|
-+
