Выбор запчасти
| № | Код | Название | Кол-во |
|---|---|---|---|
|
|
ASM-GEARCASE, X2,700/800 [Incl. All]
|
1
|
|
|
1
|
3/8X1.25X86 PITCHES,CHAIN
|
1
|
|
|
10
|
CAM,CHAIN TENSIONER
|
1
|
|
|
11
|
SHOE,CHAIN TENSIONER
|
1
|
|
|
12
|
PIN,DOWEL
|
2
|
|
|
13
|
CHAIN, .25P X .40W X 50L
|
1
|
|
|
14
|
PINION, 13T CENTER DRIVE
|
1
|
|
|
15
|
DRUM,SHIFT
|
1
|
|
|
16
|
BEARING-BALL
|
1
|
|
|
17
|
RING-RETAINING
|
1
|
|
|
18
|
SPROCKET, 19T 1.25"
|
1
|
|
|
19
|
BEARING, BALL 6204 R 20X47X14
|
2
|
|
|
2
|
SCREW
|
2
|
|
|
20
|
WASHER
|
1
|
|
|
21
|
BEARING,NDL,SPLIT CAGE
|
1
|
|
|
22
|
RING,RETAINING,BSCEXTERNAL0.84
|
1
|
|
|
23
|
WASHER,THRUST,1.300X.995X.065
|
2
|
|
|
24
|
BEARING, NEEDLE
|
2
|
|
|
25
|
DOG, L/P
|
1
|
|
|
26
|
PLATE-PARK 12 FACE
|
1
|
|
|
27
|
BEARING, BALL 6203 C3 17X40X12
|
2
|
|
|
28
|
SCREW,TAPPINGHEXHEAD1/4-20X.75
|
3
|
|
|
29
|
RING,RETAINING
|
2
|
|
|
3
|
OIL DEFLECTOR
|
1
|
|
|
30
|
GEAR, 33T 6-FACE
|
1
|
|
|
31
|
SHAFT, REVERSE 26T
|
1
|
|
|
32
|
SPROCKET 38T 6-FACE
|
1
|
|
|
33
|
ENGAGEMENT DOG 6 FACE
|
1
|
|
|
34
|
WASHER
|
1
|
|
|
35
|
GEAR, SPUR
|
1
|
|
|
36
|
RING-RETAINING
|
1
|
|
|
37
|
BEARING
|
1
|
|
|
38
|
SHAFT, INPUT
|
1
|
|
|
4
|
GEAR OUTPUT,91T
|
1
|
|
|
5
|
RING,RETAINING
|
1
|
|
|
6
|
SCREW-TORX TRUSS HD
|
5
|
|
|
7
|
COVER-CENTER DRIVE BEARING
|
1
|
|
|
8
|
SHIM 1.700 X 1.385
|
1
|
|
|
9
|
SPRING,TORSION
|
1
|
-+
