Выбор запчасти
| № | Код | Название | Кол-во |
|---|---|---|---|
|
1
|
COUVRE RES. GA *TANK COVER LH
|
1
|
|
|
10
|
PANNEAU AR DR *RH REAR PANEL
|
1
|
|
|
11
|
MOUSSE ARR DR *FOAM PANEL RH
|
1
|
|
|
12
|
GRILLE DROITE *RH GRILL
|
1
|
|
|
12a
|
PINCE *CLIP
|
4
|
|
|
13
|
EXTRUDED PANEL NUT M6 X 1.0
|
6
|
|
|
14
|
TORX-TRUSS M/S STLSS NYLON PATCH
|
2
|
|
|
15
|
ROND. PLASTIQUE*PLASTIC WASHER
|
2
|
|
|
16
|
PLASTIQUE RIVET TUFLOK
|
4
|
|
|
17
|
POIGN PASSAGER *PASSENGER HDLE
|
1
|
|
|
18
|
SCREW-HEX.FLANGE DIN.6921 S.GRIP
|
2
|
|
|
19
|
POINTE ARRIERE *REAR TIP Red
|
1
|
|
|
19
|
POINTE ARRIERE *REAR TIP Yellow
|
1
|
|
|
19
|
POINTE ARRIERE *REAR TIP Full Moon
|
1
|
|
|
2
|
MOUSSE REFL GA.*FOAM LH
|
1
|
|
|
20
|
PASSAGE ROUE *UNDER TAIL COV
|
1
|
|
|
21
|
EXTRUDED PANEL NUT M6 X 1.0
|
7
|
|
|
22
|
TORX-TRUSS M/S STLSS NYLON PATCH
|
7
|
|
|
23
|
SUPPORT GAUCHE *LH.SUPPORT
|
1
|
|
|
24
|
SUPPORT DROIT *RH.SUPPORT
|
1
|
|
|
25
|
SUPPORT AILE *FENDER SUPPORT
|
1
|
|
|
26
|
AILE ARRIERE *REAR FENDER Red
|
1
|
|
|
26
|
AILE ARRIERE *REAR FENDER Yellow
|
1
|
|
|
26
|
AILE ARRIERE *REAR FENDER Full Moon
|
1
|
|
|
27
|
AILE ARRIERE *REAR FENDER Yellow, Europe
|
1
|
|
|
27
|
AILE ARRIERE *REAR FENDER Full Moon, Europe
|
1
|
|
|
27
|
AILE ARRIERE *REAR FENDER Red, Europe
|
1
|
|
|
28
|
TORX-TRUSS M/S M6 X 20 STLSS N.PATCH
|
4
|
|
|
29
|
ROND. PLASTIQUE*PLASTIC WASHER
|
4
|
|
|
3
|
COUVRE RES. DR *TANK COVER RH
|
1
|
|
|
30
|
NUT-FLANGE ELASTIC DIN.6926
|
4
|
|
|
31
|
TORX-TRUSS M/S STLSS NYLON PATCH
|
3
|
|
|
32
|
TORX-TRUSS M/S STLSS NYLON PATCH
|
3
|
|
|
33
|
NUT-FLANGE ELASTIC DIN.6926
|
6
|
|
|
34a
|
PLAQUE RENFORT *REINF. PLATE
|
1
|
|
|
34b
|
PLAQUE RENFORT *REINF. PLATE
|
1
|
|
|
35
|
SUPPORT PLAQUE *LICENCE PL SUP Europe
|
1
|
|
|
36
|
TORX-TRUSS M/S STLSS NYLON PATCH Europe
|
4
|
|
|
37
|
NUT-STOP ELASTIC DIN.985 Europe
|
2
|
|
|
37a
|
NUT-DOMED HEXAGONAL DIN.1587 Europe
|
2
|
|
|
38
|
GARDE-COURROIE *GUARD-BELT
|
1
|
|
|
39
|
SCREW-TORX BUTTON HEAD M6 X 25
|
1
|
|
|
4
|
MOUSSE REFL DR *FOAM RH
|
1
|
|
|
40
|
GARDE-COURROIE *GUARD-BELT
|
1
|
|
|
41
|
TORX-TRUSS M/S STLSS NYLON PATCH
|
2
|
|
|
42
|
NUT-DOMED HEXAGONAL DIN.1587
|
2
|
|
|
43
|
SUPPORT GAUCHE *LH.SUPPORT
|
1
|
|
|
44
|
REPOSE-PIED GA.*LH.FOOTREST
|
1
|
|
|
45
|
TAMPON CAOUT. *PAD-RUBBER
|
1
|
|
|
46
|
SCREW-PLASTITE ALLEN BUTTON HEAD #12
|
2
|
|
|
47
|
RESSORT *SPRING
|
1
|
|
|
48
|
AXE DE RETENUE *PIN RETAINER
|
1
|
|
|
49
|
CIRCLIP *CIRCLIP
|
1
|
|
|
5
|
JOINT ETANCHE *SEAL-TRAY
|
|
|
|
50
|
SUPPORT DROIT *RH.SUPPORT
|
1
|
|
|
51
|
REPOSE-PIED DR.*RH.FOOTREST
|
1
|
|
|
52
|
TAMPON CAOUT. *PAD-RUBBER
|
1
|
|
|
53
|
SCREW-PLASTITE ALLEN BUTTON HEAD #12
|
2
|
|
|
54
|
RESSORT *SPRING
|
1
|
|
|
55
|
AXE DE RETENUE *PIN RETAINER
|
1
|
|
|
56
|
CIRCLIP *CIRCLIP
|
1
|
|
|
57
|
SCREW-HEX.FLANGE DIN.6921 S.GRIP
|
5
|
|
|
58
|
SUPPORT GAUCHE *LH.SUPPORT
|
1
|
|
|
59
|
REPOSE-PIED GA.*LH.FOOTREST
|
1
|
|
|
6
|
PLASTIQUE RIVET TUFLOK
|
7
|
|
|
60
|
TAMPON CAOUT. *PAD-RUBBER
|
1
|
|
|
61
|
SCREW-PLASTITE ALLEN BUTTON HEAD #12
|
2
|
|
|
62
|
RESSORT *SPRING
|
1
|
|
|
63
|
BILLE *BALL
|
1
|
|
|
64
|
PLAQUE INDEXA *PLATE INDEX
|
1
|
|
|
65
|
AXE DE RETENUE *PIN RETAINER
|
1
|
|
|
66
|
CIRCLIP *CIRCLIP
|
1
|
|
|
67
|
SUPPORT DROIT *RH.SUPPORT
|
1
|
|
|
68
|
REPOSE-PIED DR.*RH.FOOTREST
|
1
|
|
|
69
|
TAMPON CAOUT. *PAD-RUBBER
|
1
|
|
|
7
|
PANNEAU AR GA *LH REAR PANEL
|
1
|
|
|
70
|
SCREW-PLASTITE ALLEN BUTTON HEAD #12
|
2
|
|
|
71
|
RESSORT *SPRING
|
1
|
|
|
72
|
BILLE *BALL
|
1
|
|
|
73
|
PLAQUE INDEXA *PLATE INDEX
|
1
|
|
|
74
|
AXE DE RETENUE *PIN RETAINER
|
1
|
|
|
75
|
CIRCLIP *CIRCLIP
|
1
|
|
|
76
|
SCREW-HEX.FLANGE DIN.6921 S.GRIP
|
8
|
|
|
77
|
REFLECT. ROUGE *RED REFLECTOR
|
2
|
|
|
77
|
REFLECT.JAUNE *AMBER REFLECT Europe
|
2
|
|
|
78
|
DUAL.LOCK 3/4" *DUAL.LOCK 3/4"
|
4
|
|
|
79
|
TORX-TRUSS M/S M6 X 20 STLSS N.PATCH
|
2
|
|
|
8
|
PARE CHALEUR *HEAT SHIELD
|
1
|
|
|
80
|
WASHER-FLAT DIN.9021B-A2
|
2
|
|
|
81
|
NUT-FLANGE ELASTIC DIN.6926
|
2
|
|
|
82
|
NUT-DOMED HEXAGONAL DIN.1587 Europe
|
2
|
|
|
83
|
WASHER-FLAT DIN.9021 A2 BLACK OXIDE
|
3
|
|
|
9
|
GRILLE GAUCHE *LH GRILL
|
1
|
|
|
9a
|
PINCE *CLIP
|
4
|
-+
