| № | Код | Название | Кол-во |
|---|---|---|---|
|
1
|
FRAME,PAINTED BLACKA/B-BODYSINGLE
|
1
|
|
|
10
|
CHANNEL,BMPR-SUPPORT-BLCK RB: 1506-596
|
1
|
|
|
11
|
BRACKET,BUMPER-RH-BLACK
|
1
|
|
|
12
|
SCREW,CAP-HFH M8X1.25X16 CL8.8 Z&Y
|
6
|
|
|
13
|
BUMPER,FRONT-BLACK A-BODY
|
1
|
|
|
14
|
FASCIA,BUMPER-FRONT BLACK
|
1
|
|
|
15
|
SCREW,MACH-TSTRH-M6-1.0 X 16 BLACK
|
2
|
|
|
16
|
SCREW,BODY - 6MM
|
16
|
|
|
17
|
NUT,HEX FLG- CLINCH LOCK- M10-1.25 Z&Y
|
2
|
|
|
18
|
BRACE,A-ARM - PTD BLACK
|
1
|
|
|
19
|
SCREW,CAP-HFH M10X1.25X25 CL10.9 Z&Y
|
2
|
|
|
2
|
HEADLIGHT, ASSY-RH inc. 3-4
|
1
|
|
|
20
|
PANEL, BELLY
|
1
|
|
|
21
|
FOAM, FRAME
|
1
|
|
|
22
|
PAD,BATTERY-TOP RR
|
1
|
|
|
23
|
NUT,HEX-FLG M8X1.25 CL8 Z&Y
|
4
|
|
|
24
|
SCREW,CAP-HFH M10X1.25X16 CL10.9 Z&Y
|
4
|
|
|
25
|
FOOTREST,RH-PTD BLACK
|
1
|
|
|
26
|
ROD, SUPPORT
|
2
|
|
|
3
|
BULB,HEADLIGHT-881
|
4
|
|
|
4
|
SOCKET,MOUNTING-BALL
|
4
|
|
|
5
|
STUD,BALL-8.0 DIA X M5
|
4
|
|
|
6
|
STUD,DOUBLE END-M5X.8
|
2
|
|
|
7
|
SPRING,ADJUSTMENT-HEADLIGHT
|
2
|
|
|
8
|
KNOB,ADJUSTMENT-M5
|
2
|
|
|
9
|
SCREW,CAP-HFH M10X1.25X20 CL10.9 Z&Y
|
4
|
-+
