Выбор запчасти
| № | Код | Название | Кол-во |
|---|---|---|---|
|
1
|
RACK,REAR-TRV ASSY PLAS inc. 2
|
|
|
|
10
|
PIN,ROLL-2.5MM
|
|
|
|
11
|
COLLAR,SEAT LATCH
|
|
|
|
12
|
SPRING,MRP LATCH
|
|
|
|
13
|
BUSHING,RACK FRAME
|
|
|
|
14
|
SCREW,CAP-HFH M8X1.25X35 CL8.8 RIE BLK
|
|
|
|
15
|
SPACER,STEEL
|
|
|
|
16
|
GROMMET,RUBBER-12.7X23.8125
|
|
|
|
17
|
NUT,HEX-THK NYL M8X1.25 CL10 Z&Y
|
|
|
|
18
|
WASHER,5/16 X 1 1/8-1/16 -Z&Y
|
|
|
|
19
|
SCREW,SHOULDER-HFH M6-1.0 X 18 CL8.8 BLK
|
|
|
|
2
|
DECAL,WARNING-RACK50 LB.
|
|
|
|
20
|
BRACKET,REAR FENDER SUPPORT-RH-PAINTED
|
|
|
|
20
|
BRACKET,REAR FENDER SUPPORT-LH-PAINTED
|
|
|
|
21
|
WASHER,FLAT- 1/4 X .734 X .063 Z&Y
|
|
|
|
22
|
NUT,FLANGE-LOCK-M6
|
|
|
|
3
|
SCREW,CAP-HFH M6X1.0X40 CL8.8 RIE BLK
|
|
|
|
4
|
WASHER,FLAT STD 1/4 DIA BLK
|
|
|
|
5
|
NUT,HEX DOMED-SELF LOCKING-M6X1.0
|
|
|
|
6
|
SCREW,CAP-HFH M6X1.0X45 CL8.8 RIE BLK
|
|
|
|
7
|
BRACKET,FLAG-SAFETY-PAINTED
|
|
|
|
8
|
RACK,REAR FRAME-ASSY inc. 9-13
|
|
|
|
9
|
PIN,MRP-ASSY inc. 10-12
|
|
-+
