| Код | Кол-во | Примечание |
|---|---|---|
| 1 fixing bracket | ||
|
001
|
|
|
| 2 Фиксатор выхл/труб. | ||
|
002
|
D=42,D1=9
|
|
| 3 Фиксатор выхл/труб. | ||
|
002
|
D=34,D1=9
|
|
| 4 hexagon screw, metric thread | ||
|
002
|
M8X20 8.8
|
|
| 5 hexagon nut, metric thread | ||
|
002
|
M8
|
|
| 6 spring washer, arched | ||
|
002
|
M8
|
|
| 7 Z-bracket | ||
|
001
|
|
|
| 8 hexagon bolt, metric thread | ||
|
001
|
M10X25 8.8
|
|
| 9 hexagon nut, metric thread | ||
|
001
|
M10
|
|
| 10 spring washer, arched | ||
|
001
|
M10
|
|
| 11 bracket, brake system | ||
|
001
|
|
|
| 12 hexagon bolt, metric thread | ||
|
002
|
M8X40
|
|
| 13 hexagon nut, metric thread | ||
|
002
|
M8
|
|
| 14 spring washer, arched | ||
|
002
|
M8
|
|
| 15 hexagon bolt, metric thread | ||
|
002
|
|
|
| 16 hexagon bolt, metric thread | ||
|
002
|
M6X55 8.8
|
|
| 17 hexagon nut, metric thread | ||
|
004
|
M6
|
|
| 18 spring washer, arched | ||
|
004
|
M6
|
|
| 19 hexagon bolt, metric thread | ||
|
006
|
|
|
| 20 protective hose | ||
|
001
|
D1=50
|
|
| 21 quick-release coupling holder | ||
|
003
|
|
|
| 22 hose smaller than 16mm | ||
|
X
|
D=8,L=10M
|
|
| 23 reinforcement sleeve | ||
|
001
|
8
|
|
| 24 clamp-cutting ring, part for pipe coupling | ||
|
001
|
8
|
|
| 25 union nut, part for pipe coupling | ||
|
001
|
M14X1.5,D=8mm
|
|
| 26 hose smaller than 16mm | ||
|
X
|
D=8,L=10M
|
|
| 27 reinforcement sleeve | ||
|
001
|
8
|
|
| 28 clamp-cutting ring, part for pipe coupling | ||
|
001
|
8
|
|
| 29 union nut, part for pipe coupling | ||
|
001
|
M14X1.5,D=8mm
|
|
| 30 hose smaller than 16mm | ||
|
X
|
D=8,L=10M
|
|
| 31 reinforcement sleeve | ||
|
001
|
8
|
|
| 32 clamp-cutting ring, part for pipe coupling | ||
|
001
|
8
|
|
| 33 union nut, part for pipe coupling | ||
|
001
|
M14X1.5,D=8mm
|
|
| 34 hose smaller than 16mm | ||
|
X
|
|
|
|
X
|
D=10mm,L=100M
|
|
| 35 reinforcement sleeve | ||
|
001
|
D=10
|
|
| 36 clamp-cutting ring, part for pipe coupling | ||
|
001
|
D=10mm
|
|
| 37 union nut, part for pipe coupling | ||
|
001
|
M16X1.5,D=10mm
|
|
| 38 hose smaller than 16mm | ||
|
X
|
|
|
|
X
|
D=10mm,L=100M
|
|
| 39 reinforcement sleeve | ||
|
001
|
D=10
|
|
| 40 clamp-cutting ring, part for pipe coupling | ||
|
001
|
D=10mm
|
|
| 41 union nut, part for pipe coupling | ||
|
001
|
M16X1.5,D=10mm
|
|
| 42 hose smaller than 16mm | ||
|
X
|
D=6,L=10M
|
|
| 43 reinforcement sleeve | ||
|
001
|
|
|
| 44 clamp-cutting ring, part for pipe coupling | ||
|
001
|
|
|
| 45 union nut, part for pipe coupling | ||
|
001
|
M12X1.5 D=6mm
|
|
| 46 hose smaller than 16mm | ||
|
X
|
D=6,L=10M
|
|
| 47 reinforcement sleeve | ||
|
001
|
|
|
| 48 clamp-cutting ring, part for pipe coupling | ||
|
001
|
|
|
| 49 union nut, part for pipe coupling | ||
|
001
|
M12X1.5 D=6mm
|
|
| 50 hose smaller than 16mm | ||
|
X
|
D=6,L=10M
|
|
| 51 reinforcement sleeve | ||
|
001
|
|
|
| 52 clamp-cutting ring, part for pipe coupling | ||
|
001
|
|
|
| 53 union nut, part for pipe coupling | ||
|
001
|
M12X1.5 D=6mm
|
|
| 54 hose smaller than 16mm | ||
|
X
|
D=8,L=10M
|
|
| 55 reinforcement sleeve | ||
|
001
|
8
|
|
| 56 clamp-cutting ring, part for pipe coupling | ||
|
001
|
8
|
|
| 57 union nut, part for pipe coupling | ||
|
001
|
M14X1.5,D=8mm
|
|
| 58 quick-release coupling, male | ||
|
002
|
|
|
| 59 quick-release coupling, female | ||
|
001
|
|
|
| 60 quick-release coupling, male | ||
|
004
|
|
|
| 61 quick-release coupling, female | ||
|
002
|
|
|
| 62 L-bracket, 90 degrees | ||
|
001
|
160X35X3
|
|
| 63 hexagon bolt, metric thread | ||
|
001
|
M12X25 8.8
|
|
| 64 hexagon nut, metric thread | ||
|
001
|
M12 8
|
|
| 65 spring washer, arched | ||
|
001
|
M12
|
|
| 66 Фиксатор выхл/труб. | ||
|
003
|
D=52,D1=9
|
|
| 67 hexagon screw, metric thread | ||
|
003
|
M8X20 8.8
|
|
| 68 hexagon nut, metric thread | ||
|
003
|
M8
|
|
| 69 spring washer, arched | ||
|
003
|
M8
|
|
| 70 Проходн. резин. втулка | ||
|
001
|
D=70,B=3
|
|
-+
