| Код | Кол-во | Примечание |
|---|---|---|
| 1 Масляный поддон | ||
|
001
|
|
|
| 2 copper sealing washer | ||
|
001
|
26.3X31.9X2mm
|
|
| 3 sealing plug, fine metric thread | ||
|
001
|
|
|
| 4 Прокладка масляного поддона | ||
|
001
|
|
|
| 5 cylinder head screw with hexagon socket and metric thread | ||
|
040
|
M8X20
|
|
| 6 filler plate | ||
|
040
|
|
|
| 7 cylinder head screw | ||
|
002
|
M8X25
|
|
| 8 fixing bracket | ||
|
001
|
|
|
| 9 hexagon bolt, metric thread | ||
|
002
|
M10X35
|
|
| 10 Шестерня, масляный насос | ||
|
001
|
|
|
| 11 oil pump, idler gear shaft | ||
|
001
|
|
|
| 12 Втулка для суппорта | ||
|
001
|
|
|
| 13 hexagon bolt, fine metric thread | ||
|
001
|
|
|
| 14 plain washer, hard | ||
|
001
|
10.5x21x2mm
|
|
| 15 oil pump housing, engine | ||
|
001
|
|
|
| 16 Вал масляного насоса | ||
|
001
|
|
|
| 17 Вал масляного насоса | ||
|
001
|
|
|
| 18 Шестерня, масляный насос | ||
|
001
|
|
|
| 19 cylindrical dowel pin | ||
|
002
|
|
|
| 20 hexagon bolt, metric thread | ||
|
003
|
M8X60
|
|
| 21 bracket, lubrication system | ||
|
001
|
|
|
| 22 hexagon screw, metric thread | ||
|
002
|
M8X20 8.8
|
|
| 23 hexagon screw, metric thread | ||
|
004
|
M8X20 8.8
|
|
| 24 Коробка | ||
|
001
|
|
|
| 25 strainer, engine | ||
|
001
|
|
|
| 26 plain washer, hard | ||
|
002
|
M6
|
|
| 27 hexagon screw, metric thread | ||
|
002
|
M6X12
|
|
| 28 Уплотнительное кольцо | ||
|
002
|
D=32
|
|
| 29 Вытяжная труба масла | ||
|
001
|
|
|
| 30 hexagon bolt, metric thread | ||
|
002
|
M8X75 8.8
|
|
| 31 plain washer, hard | ||
|
002
|
D1=8.4
|
|
| 32 plain washer, hard | ||
|
004
|
D1=8.4
|
|
| 33 hexagon bolt, metric thread | ||
|
002
|
M8X80
|
|
| 34 oil pipe, delivery side | ||
|
001
|
|
|
| 35 Уплотнительное кольцо | ||
|
002
|
|
|
| 36 oil pressure regulator | ||
|
001
|
|
|
| 37 hexagon bolt, metric thread | ||
|
004
|
M8X50
|
|
| 38 Регулирующий клапан | ||
|
001
|
|
|
| 39 Пружина компрессора | ||
|
001
|
|
|
| 40 copper sealing washer | ||
|
001
|
30.3x35.9x2 mm
|
|
| 41 Уплотн. заглушка | ||
|
001
|
|
|
| 42 Сфера | ||
|
001
|
|
|
| 43 Пружина компрессора | ||
|
001
|
|
|
| 44 plain washer, normal | ||
|
001
|
M10
|
|
| 45 Шпилька | ||
|
001
|
4X45mm
|
|
| 46 oil pipe, delivery side | ||
|
001
|
|
|
| 47 Уплотнительное кольцо | ||
|
002
|
|
|
| 48 connecting bend, lubrication system elements | ||
|
001
|
|
|
| 49 hexagon bolt, metric thread | ||
|
002
|
M8X25
|
|
| 50 engine oil pump | ||
|
001
|
|
|
-+
