| Код | Кол-во | Примечание |
|---|---|---|
| 1 coolant pump, engine | ||
|
001
|
|
|
| 2 gasket, coolant pump | ||
|
001
|
|
|
| 3 flange bolt 10.9 | ||
|
007
|
M8X50
|
|
| 4 flange bolt 10.9 | ||
|
002
|
M8X75 10.9
|
|
| 5 coolant pipe from pump to thermostat housing | ||
|
001
|
|
|
| 6 Уплотнительное кольцо | ||
|
002
|
|
|
| 7 valve seat, thermostat | ||
|
001
|
|
|
| 8 seal ring between coolant pump and thermostat | ||
|
001
|
57.7X67.5X6.4
|
|
| 9 thermostat, coolant | ||
|
001
|
T1=87
|
|
| 10 Уплотнительное кольцо | ||
|
001
|
|
|
| 11 flange bolt 10.9 | ||
|
002
|
M8X110
|
|
| 12 flange bolt 10.9 | ||
|
001
|
M8X90
|
|
| 13 coolant pipe 01, cylinder head | ||
|
001
|
|
|
| 14 coolant pipe, cylinder head centre | ||
|
001
|
|
|
| 15 Уплотнительное кольцо | ||
|
002
|
|
|
| 16 coolant pipe 02, cylinder head | ||
|
001
|
|
|
| 17 flange gasket, coolant pipe | ||
|
006
|
|
|
| 18 flange bolt 10.9 | ||
|
011
|
M8X50
|
|
| 19 flange bolt 10.9 | ||
|
001
|
M8X100
|
|
| 20 male or female hose nipple | ||
|
001
|
|
|
| 21 copper sealing washer | ||
|
001
|
26.3x33.9x2 mm
|
|
| 22 Трубка охлажд. жидк. | ||
|
001
|
|
|
| 23 Уплотнительное кольцо | ||
|
002
|
|
|
| 24 coolant pipe from pump to radiator | ||
|
001
|
|
|
| 25 flange nut, hexagon, metric thread, smooth | ||
|
003
|
M8-10
|
|
| 26 male or female hose nipple | ||
|
001
|
|
|
| 27 copper sealing washer | ||
|
001
|
26.3x33.9x2 mm
|
|
| 28 coolant pipe 01, cylinder block | ||
|
001
|
|
|
| 29 Уплотнительное кольцо | ||
|
001
|
|
|
| 30 flange bolt 10.9 | ||
|
002
|
M8X20 10.9
|
|
| 31 connecting bend, cooling system | ||
|
001
|
|
|
| 32 Уплотнительное кольцо | ||
|
001
|
D=25mm
|
|
| 33 Уплотнительное кольцо | ||
|
001
|
D=33
|
|
| 34 flange bolt 10.9 | ||
|
002
|
M8X25 10.9
|
|
| 35 connecting bend, cooling system | ||
|
001
|
|
|
| 36 Уплотнительное кольцо | ||
|
001
|
D=33
|
|
| 37 flange bolt 10.9 | ||
|
002
|
M8X25 10.9
|
|
| 38 male or female hose nipple | ||
|
001
|
|
|
| 39 copper sealing washer | ||
|
001
|
26.3x33.9x2 mm
|
|
| 40 coolant hose, oil cooler | ||
|
001
|
|
|
| 41 Хомут шланга | ||
|
001
|
|
|
| 42 Хомут шланга | ||
|
001
|
D=28
|
|
| 43 sealing plug, fine metric thread | ||
|
001
|
M14X1,5
|
|
| 44 copper sealing washer | ||
|
001
|
14.2x19.9x1.5mm
|
|
| 45 Сопряжение типа банджо | ||
|
001
|
|
|
| 46 Пустотелый винт | ||
|
001
|
|
|
| 47 copper sealing washer | ||
|
002
|
14.2x19.9x1.5mm
|
|
| 48 sealing plug, fine metric thread | ||
|
001
|
M14X1,5
|
|
| 49 copper sealing washer | ||
|
001
|
14.2x19.9x1.5mm
|
|
| 50 sealing plug, fine metric thread | ||
|
001
|
M16X1,5
|
|
| 51 copper sealing washer | ||
|
001
|
16.2x21.9x1.3mm
|
|
| 52 Коробка термостата | ||
|
001
|
|
|
| 999 sealing plug, fine metric thread | ||
|
001
|
M14X1,5
|
|
|
001
|
|
|
|
001
|
|
|
|
001
|
|
|
-+
