| Код | Кол-во | Примечание |
|---|---|---|
| 1 Воздушный компрессор | ||
|
001
|
|
|
| 2 Уплотнительное кольцо | ||
|
001
|
|
|
| 3 flange bolt 10.9 | ||
|
004
|
M12X80
|
|
| 4 Шестерня привода компрессора | ||
|
001
|
|
|
| 5 flange bolt, metric thread, smooth | ||
|
001
|
|
|
| 6 plain washer, hardened | ||
|
001
|
|
|
| 7 Кронштейн компрессора | ||
|
001
|
|
|
| 8 flange bolt 10.9 | ||
|
002
|
M8X16
|
|
| 9 flange bolt 10.9 | ||
|
002
|
M10X20 10.9
|
|
| 10 male or female hose nipple | ||
|
003
|
|
|
|
003
|
|
|
| 11 copper sealing washer | ||
|
003
|
14.2x19.9x1.5mm
|
|
| 12 Сопряжение типа банджо | ||
|
001
|
|
|
| 13 copper sealing washer | ||
|
002
|
14.2x19.9x1.5mm
|
|
| 14 Пустотелый винт | ||
|
001
|
M14X26
|
|
| 15 Хомут шланга | ||
|
004
|
D=11-17
|
|
| 17 Гибкий шланг | ||
|
PM
|
D=9
|
|
| 18 oil pipe, delivery side | ||
|
001
|
|
|
| 19 clamp-cutting ring, part for pipe coupling | ||
|
001
|
d=6,D=9mm
|
|
| 20 union nut, part for pipe coupling | ||
|
001
|
M12X1.5 D=6mm
|
|
| 21 Пустотелый винт | ||
|
001
|
M10X1
|
|
| 22 copper sealing washer | ||
|
001
|
10.2x14.9x1.0mm
|
|
| 23 shouldered stud | ||
|
001
|
|
|
| 24 pipe clip for 1 or 2 lines | ||
|
001
|
D=6,d=6.4mm
|
|
| 25 flange nut, hexagon, metric thread, smooth | ||
|
001
|
M6
|
|
| 26 male coupling, part for pipe coupling | ||
|
001
|
|
|
| 27 copper sealing washer | ||
|
001
|
26.3X31.9X2mm
|
|
| 28 compressor pipe 01, suction side | ||
|
001
|
|
|
|
001
|
|
|
| 29 union nut, part for pipe coupling | ||
|
001
|
M30X2,D=22mm
|
|
| 30 clamp-cutting ring, part for pipe coupling | ||
|
001
|
D=22mm
|
|
| 31 rectangular fixation plate | ||
|
001
|
|
|
| 32 pipe clip for 1 or 2 lines | ||
|
001
|
D=22,d=8.4mm
|
|
| 33 flange bolt 10.9 | ||
|
001
|
M8X20 10.9
|
|
| 34 male coupling, part for pipe coupling | ||
|
001
|
|
|
| 35 copper sealing washer | ||
|
001
|
26.3X31.9X2mm
|
|
| 36 Кронштейн компрессора | ||
|
001
|
|
|
| 37 flange bolt 10.9 | ||
|
002
|
M8X16
|
|
| 38 part for pipe coupling, general | ||
|
001
|
|
|
| 39 check nut | ||
|
001
|
M26X1,5
|
|
| 40 Предохранительный клапан | ||
|
001
|
|
|
| 41 compressor pipe 01, delivery side | ||
|
001
|
|
|
| 42 clamp-cutting ring, part for pipe coupling | ||
|
002
|
|
|
| 43 union nut, part for pipe coupling | ||
|
002
|
M26X1.5,D=18mm
|
|
| 50 Пластина крепления | ||
|
001
|
|
|
| 51 compressor pipe, air dryer command | ||
|
001
|
|
|
|
001
|
|
|
| 52 union nut, part for pipe coupling | ||
|
001
|
M12X1.5 D=6mm
|
|
| 53 clamp-cutting ring, part for pipe coupling | ||
|
001
|
d=6,D=9mm
|
|
| 54 Пустотелый винт | ||
|
001
|
M12X24
|
|
| 55 copper sealing washer | ||
|
002
|
12x17x1.5 mm
|
|
| 56 pipe clip for 1 or 2 lines | ||
|
001
|
D=6,d=6.4mm
|
|
| 57 hexagon screw, metric thread | ||
|
001
|
M6X22mm
|
|
| 58 flange nut, hexagon, metric thread, smooth | ||
|
001
|
M6
|
|
| 59 quick-acting coupling, straight | ||
|
001
|
|
|
|
001
|
|
|
| 60 check nut | ||
|
001
|
M12X1,5
|
|
| 61 flange bolt 10.9 | ||
|
002
|
M8X80 10.9
|
|
| 999 clamp-cutting ring, part for pipe coupling | ||
|
001
|
D=22mm
|
|
|
001
|
d=6,D=9mm
|
|
|
002
|
|
|
|
001
|
M12X1,5
|
|
|
001
|
M10X1
|
|
|
001
|
M14X26
|
|
|
001
|
M12X24
|
|
|
001
|
|
|
|
001
|
M26X1,5
|
|
|
003
|
|
|
|
001
|
|
|
|
003
|
|
|
|
001
|
|
|
-+
