| Код | Кол-во | Примечание |
|---|---|---|
| 1 10-hole wheel hub, disc brake | ||
|
002
|
|
|
| 2 pulse ring | ||
|
002
|
|
|
| 3 wheel bolt | ||
|
020
|
M22X1.5X70
|
|
| 4 Крепежная гайка колеса | ||
|
020
|
Fr,M22x1.5x39mm
|
|
| 5 wheel nut cover | ||
|
020
|
M22,L=34
|
|
| 6 stub axle, brake disc | ||
|
001
|
lh 156NS
|
|
| 7 stub axle, brake disc | ||
|
001
|
RH 156NS
|
|
| 8 Крышка ступицы | ||
|
002
|
|
|
| 9 Уплотнительное кольцо | ||
|
002
|
|
|
| 10 screw with pan head and hexalobular socket | ||
|
008
|
M6X16
|
|
| 11 Гайка ступицы | ||
|
002
|
M58X1.5
|
|
| 12 Стопорная шайба | ||
|
002
|
|
|
| 13 Поворотный шкворень | ||
|
002
|
|
|
| 14 Кольцо | ||
|
002
|
50X31.5mm
|
|
| 15 hexagon nut, metric thread | ||
|
002
|
M27
|
|
| 16 stub axle, cover 1 | ||
|
002
|
|
|
| 17 Уплотнительное кольцо | ||
|
002
|
66.34X2.62mm
|
|
| 18 screw with pan head and hexalobular socket | ||
|
004
|
M6x12
|
|
| 19 Пресс-масленка | ||
|
002
|
KLN
|
|
| 20 Калибров. прокладка | ||
|
X
|
S=1.5mm
|
|
|
X
|
S=1,75mm
|
|
|
X
|
S=1,88mm
|
|
|
X
|
S=2mm
|
|
|
X
|
S=2.13mm
|
|
|
X
|
S=2.25mm
|
|
|
X
|
S=2.38mm
|
|
| 21 Ручаг рулевого управления | ||
|
001
|
|
|
| 22 flange bolt, smooth, metric thread | ||
|
002
|
M22X80
|
|
| 23 needle bearing, front axle | ||
|
004
|
50X58.0X20.0mm
|
|
| 24 seal ring, front axle | ||
|
002
|
50.0X6.0mm
|
|
| 25 needle bearing, front axle | ||
|
004
|
|
|
| 26 blanking plate, stub axle | ||
|
002
|
|
|
| 27 Пресс-масленка | ||
|
002
|
M8X1
|
|
| 28 flange bolt 10.9 | ||
|
008
|
M8X16
|
|
| 29 flange bolt, smooth, metric thread | ||
|
004
|
M22X80
|
|
| 30 hexagon screw, metric thread | ||
|
002
|
M20X40 8.8
|
|
| 31 hexagon nut, metric thread | ||
|
002
|
M20
|
|
| 32 Зажимная втулка | ||
|
002
|
|
|
| 33 Датчик скорости колеса | ||
|
001
|
|
|
| 34 Датчик скорости колеса | ||
|
001
|
|
|
| 38 fixing spring clip | ||
|
002
|
|
|
| 39 seal ring, front axle | ||
|
002
|
|
|
| 40 collar ring | ||
|
002
|
|
|
| 41 thrust washer, stub axle | ||
|
002
|
|
|
| 42 collar ring | ||
|
002
|
|
|
| 43 repair kit, stub axle with disc brake | ||
|
002
|
152N
|
|
-+
