| Код | Кол-во | Примечание |
|---|---|---|
| 1 dosing module, EAS | ||
|
001
|
LF
|
|
| 2 fixing bracket | ||
|
001
|
EAS
|
|
| 3 air filter, EAS | ||
|
001
|
|
|
| 4 AdBlue nozzle | ||
|
001
|
|
|
| 5 Соединительная гайка | ||
|
001
|
M35X1.5,sw=38
|
|
| 6 Датчик температуры на выпуске | ||
|
001
|
BK
|
|
| 7 exhaust gas temperature sensor after the catalyst | ||
|
001
|
GY
|
|
| 8 AdBlue hose | ||
|
001
|
Инжекция
|
|
| 9 AdBlue hose | ||
|
001
|
Возврат
|
|
| 10 AdBlue hose | ||
|
001
|
FEED
|
|
| 11 hose smaller than 16mm | ||
|
001
|
6X1X5000mm,GN
|
|
| 12 flange bolt 10.9 | ||
|
002
|
M12X30 10.9
|
|
| 13 flange nut, hexagon, metric thread, smooth | ||
|
002
|
M12-10
|
|
| 14 flange bolt 10.9 | ||
|
004
|
M8X50
|
|
| 15 flange nut, hexagon, metric thread, smooth | ||
|
004
|
M8-10
|
|
| 16 flange bolt 10.9 | ||
|
002
|
M8X35
|
|
| 17 flange nut, hexagon, metric thread, smooth | ||
|
002
|
M8-10
|
|
| 18 flange bolt 10.9 | ||
|
002
|
M12X30 10.9
|
|
| 19 flange nut, hexagon, metric thread, smooth | ||
|
002
|
M12-10
|
|
| 20 NOx sensor after the catalyst | ||
|
001
|
|
|
| 21 bracket, electrical system | ||
|
001
|
|
|
| 22 Изолирующее кольцо | ||
|
004
|
|
|
| 23 plain washer, hard | ||
|
002
|
6.4X12X1.6mm
|
|
| 24 all-metal prevailing torque hexagon nut | ||
|
002
|
M6
|
|
| 25 electrical cable guidance | ||
|
001
|
|
|
| 26 flange bolt 10.9 | ||
|
002
|
M8X30
|
|
| 27 flange nut, hexagon, metric thread, smooth | ||
|
002
|
M8-10
|
|
| 101 plastic clamping strap | ||
|
005
|
L=270,B=7.0mm
|
|
|
005
|
L=203,B=7.6mm
|
|
|
005
|
L=203,B=7.6mm
|
|
| 999 flange bolt 10.9 | ||
|
002
|
M12X30 10.9
|
|
|
001
|
6X1X5000mm,GN
|
|
-+
