Выбор запчасти
Например
XLRAS47XS5E701948
| Код | Кол-во | Примечание |
|---|---|---|
| 1 Воздушный компрессор | ||
|
001
|
|
|
|
001
|
|
|
| 2 Уплотнительное кольцо | ||
|
001
|
|
|
| 3 hexagon bolt, metric thread | ||
|
004
|
M12X85 8.8
|
|
| 4 plain washer, hard | ||
|
004
|
D=13,S=2.5mm
|
|
| 5 Шестерня привода компрессора | ||
|
001
|
|
|
| 6 plain washer, hardened | ||
|
001
|
|
|
| 7 flange bolt, metric thread, smooth | ||
|
001
|
|
|
| 8 copper sealing washer | ||
|
001
|
26.3X31.9X2mm
|
|
| 9 sealing plug, fine metric thread | ||
|
001
|
M26X1,5
|
|
| 10 Пустотелый винт | ||
|
003
|
M14X26
|
|
| 11 Хомут шланга | ||
|
004
|
D=12-20
|
|
| 12 Гибкий шланг | ||
|
PM
|
D=9
|
|
| 13 Маслопроводная трубка | ||
|
001
|
|
|
|
001
|
|
|
| 14 clamp-cutting ring, part for pipe coupling | ||
|
001
|
d=6,D=9mm
|
|
| 15 union nut, part for pipe coupling | ||
|
001
|
M12X1.5 D=6mm
|
|
| 16 Пустотелый винт | ||
|
001
|
M10X1
|
|
| 17 copper sealing washer | ||
|
002
|
10.2x14.9x1.0mm
|
|
| 18 male coupling, part for pipe coupling | ||
|
001
|
|
|
| 19 copper sealing washer | ||
|
001
|
26.3X31.9X2mm
|
|
| 20 Труба компрессора | ||
|
001
|
|
|
| 21 union nut, part for pipe coupling | ||
|
001
|
M30X2,D=22mm
|
|
| 22 clamp-cutting ring, part for pipe coupling | ||
|
001
|
D=22mm
|
|
| 23 pipe clip for 1 or 2 lines | ||
|
001
|
D=22,d=8.4mm
|
|
| 24 hexagon screw, metric thread | ||
|
001
|
M8X16
|
|
| 25 obtuse V-bracket | ||
|
001
|
70X70X3
|
|
| 26 Фиксатор выхл/труб. | ||
|
001
|
D=18,d=9mm
|
|
| 27 hexagon screw, metric thread | ||
|
001
|
M8X20 8.8
|
|
| 28 КрепЁжный угольник | ||
|
001
|
|
|
| 29 bulkhead, part for pipe coupling | ||
|
001
|
|
|
| 30 check nut | ||
|
001
|
|
|
| 31 shouldered stud | ||
|
001
|
M8X20X16X5
|
|
| 32 spring washer, waved | ||
|
001
|
M8
|
|
| 33 Труба компрессора | ||
|
001
|
|
|
| 34 clamp-cutting ring, part for pipe coupling | ||
|
002
|
|
|
| 35 union nut, part for pipe coupling | ||
|
002
|
M26X1.5,D=18mm
|
|
| 36 part for pipe coupling, general | ||
|
001
|
|
|
| 37 Предохранительный клапан | ||
|
001
|
|
|
|
001
|
|
|
| 38 check nut | ||
|
001
|
|
|
| 39 L-bracket | ||
|
001
|
|
|
| 40 Труба компрессора | ||
|
001
|
|
|
| 41 clamp-cutting ring, part for pipe coupling | ||
|
002
|
|
|
| 42 union nut, part for pipe coupling | ||
|
002
|
M26X1.5,D=18mm
|
|
| 43 male coupling, part for pipe coupling | ||
|
001
|
|
|
| 44 copper sealing washer | ||
|
001
|
26.3X31.9X2mm
|
|
| 46 hexagon bolt, metric thread | ||
|
002
|
M10X20 8.8
|
|
| 47 Плоская шайба | ||
|
002
|
|
|
| 48 hexagon nut, metric thread | ||
|
004
|
M8
|
|
| 49 Плоская шайба | ||
|
003
|
|
|
| 50 L-bracket | ||
|
001
|
|
|
| 51 male or female hose nipple | ||
|
001
|
|
|
| 52 Сопряжение типа банджо | ||
|
003
|
|
|
| 53 copper sealing washer | ||
|
007
|
14.2x19.9x1.5mm
|
|
| 54 shouldered stud | ||
|
001
|
|
|
| 55 pipe clip for 1 or 2 lines | ||
|
001
|
D=6,d=6.4mm
|
|
| 56 flange nut, hexagon, metric thread, smooth | ||
|
001
|
M6
|
|
-+
