| Код | Кол-во | Примечание |
|---|---|---|
| 1 air reservoir bracket | ||
|
001
|
|
|
| 2 bracket, cooling system | ||
|
001
|
|
|
| 3 flange bolt, metric thread, smooth | ||
|
002
|
M12X25
|
|
| 4 flange nut, hexagon, metric thread, smooth | ||
|
002
|
M12
|
|
| 5 flange bolt, metric thread, smooth | ||
|
002
|
|
|
| 6 flange nut, hexagon, metric thread, smooth | ||
|
002
|
|
|
| 7 Крюк | ||
|
004
|
|
|
| 8 Кронштейн | ||
|
002
|
|
|
| 9 hexagon nut with non-metallic insert | ||
|
004
|
M8X1,25
|
|
| 10 Уплотн. заглушка | ||
|
001
|
M22X1.5X18
|
|
| 11 seal ring, part for pipe coupling | ||
|
003
|
|
|
| 12 blow-off valve | ||
|
001
|
HANDBEDIEND
|
|
| 13 male coupling, part for pipe coupling | ||
|
002
|
|
|
| 14 seal ring, part for pipe coupling | ||
|
002
|
|
|
| 15 check nut | ||
|
002
|
M22X1,5
|
|
| 16 test connector, pneumatic, female | ||
|
001
|
M16X1,5
|
|
| 17 male coupling, part for pipe coupling | ||
|
001
|
|
|
| 18 hose smaller than 16mm | ||
|
X
|
D=15,L=10M
|
|
| 19 reinforcement sleeve | ||
|
002
|
15
|
|
| 20 clamp-cutting ring, part for pipe coupling | ||
|
002
|
15
|
|
| 21 union nut, part for pipe coupling | ||
|
002
|
M22X1.5 D=15
|
|
| 22 plastic clamping strap | ||
|
X
|
L=203,B=7.6mm
|
|
| 23 fixing bracket | ||
|
001
|
|
|
| 24 fixing strip | ||
|
001
|
|
|
| 25 hexagon screw, metric thread | ||
|
001
|
M8X20 8.8
|
|
| 26 hexagon nut, metric thread | ||
|
001
|
M8
|
|
| 27 spring washer, arched | ||
|
001
|
M8
|
|
| 28 Тормозная магистраль | ||
|
001
|
C
|
|
| 29 union nut, part for pipe coupling | ||
|
002
|
M26X1.5,D=18mm
|
|
| 30 clamp-cutting ring, part for pipe coupling | ||
|
002
|
|
|
| 31 coupling, part for pipe coupling | ||
|
002
|
|
|
| 32 Лента | ||
|
002
|
|
|
| 33 Фиксатор выхл/труб. | ||
|
005
|
D=17,D1=17
|
|
| 34 hexagon bolt, metric thread | ||
|
005
|
|
|
| 35 hexagon nut with non-metallic insert | ||
|
005
|
M6X1
|
|
| 36 plain washer, normal | ||
|
005
|
M6
|
|
| 37 air reservoir | ||
|
001
|
|
|
| 38 shouldered stud, fine thread | ||
|
001
|
|
|
| 39 seal ring, part for pipe coupling | ||
|
001
|
|
|
| 40 check nut | ||
|
002
|
M22X1,5
|
|
| 41 fixing bracket | ||
|
001
|
|
|
| 42 hexagon bolt, metric thread | ||
|
002
|
M12X25 8.8
|
|
| 43 hexagon nut, metric thread | ||
|
002
|
M12 8
|
|
| 44 spring washer, arched | ||
|
002
|
M12
|
|
| 45 shouldered stud, fine thread | ||
|
001
|
|
|
| 46 seal ring, part for pipe coupling | ||
|
001
|
|
|
| 47 check nut | ||
|
001
|
M22X1,5
|
|
| 48 male coupling, part for pipe coupling | ||
|
001
|
|
|
| 49 seal ring, part for pipe coupling | ||
|
001
|
|
|
| 50 hose smaller than 16mm | ||
|
X
|
D=6,L=10M
|
|
| 51 reinforcement sleeve | ||
|
002
|
|
|
| 52 clamp-cutting ring, part for pipe coupling | ||
|
002
|
|
|
| 53 union nut, part for pipe coupling | ||
|
002
|
M12X1.5 D=6mm
|
|
| 54 Тормозная магистраль | ||
|
001
|
C
|
|
| 55 union nut, part for pipe coupling | ||
|
002
|
M26X1.5,D=18mm
|
|
| 56 clamp-cutting ring, part for pipe coupling | ||
|
002
|
|
|
| 57 hexagon bolt, metric thread | ||
|
002
|
M8X25
|
|
| 58 adapter bush | ||
|
002
|
|
|
| 59 plain washer, hard | ||
|
003
|
8.4x17x1.6 mm
|
|
| 60 spring washer, arched | ||
|
002
|
M8
|
|
| 61 Проходн. резин. втулка | ||
|
002
|
|
|
| 63 lock washer, serrated | ||
|
002
|
|
|
-+
